Tractor · 1985Unverified
Iseki TA410
Iseki TA410 — Landleader TA0 Series · 40 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
3847 to 4244 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Four-post ROPS. Cab optional.Reference
Engine
Isuzu 2.2L 4-cyl dieselReference
Fuel tank51.1 LReference
Engine30.1 kWReference
Isuzu 4JC1Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke88 x 92 mmReference
Power30.1 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
Gears16 forward and reverseReference
PTO & Hydraulics
Rear TypeJIS1Reference
Rear PTO Type540 (1.375)Reference
Engine RPM565@2500Reference
Engine RPM677@2500Reference
Engine RPM821@2500Reference
Engine RPM1270@2500Reference
Dimensions
Wheelbase197 cmReference
Weight3847 to 4244 poundsReference
Front tire6.00-16Reference
2WD Rear tire13.6-28Reference
2WD Standard tires (ag)Front: 6.00-16. Rear: 13.6-28Reference
4WD Standard tires (ag)Front: 8-18. Rear: 13.6-28Reference
Length341 cmReference
Width155 cmReference
Height219 cmReference
2WD Weight1744 kgReference
4WD Weight1925 kgReference
Ground clearance36 cmReference
2WD Front tread115 to 154 cmReference
4WD Front tread121 cmReference
Rear tread121 to 162 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
