Tractor · 1993Unverified
Iseki TA537
Iseki TA537 — TA500 Series · 37 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Weight
1534 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Built in JapanReference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post folding ROPS. Cab available with air-conditioning.Reference
Engine
Isuzu 2.0L 4-cyl dieselReference
Fuel tank48.1 LReference
Engine27.6 kWReference
Isuzu 4JD1Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.0 LReference
Bore/Stroke84 x 92 mmReference
Power27.6 kWReference
Rated RPM2600Reference
Torque125.6 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity7.0 LReference
Exhaust valve clearance0.406 mmReference
Transmission
16-speed shuttleReference
TypeshuttleReference
Gears16 forward and reverseReference
Oil capacity28.8 LReference
PTO & Hydraulics
Pressure151.7 barReference
Total flow29.1 lpmReference
Steering flow22.7 lpmReference
Rear TypeIIReference
Rear lift (at ends)1799 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase189 cmReference
Weight1534 kgReference
Front tire8x18Reference
Rear tire13.6-26Reference
Ag front8x18Reference
Ag rear13.6-26Reference
Length329 cmReference
Width152 cmReference
Height155 cmReference
Height (cab)232 cmReference
Ground clearance36 cmReference
Front tread120 cmReference
Rear tread114 to 249 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Battery volts12Reference
Battery AH45Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
