Tractor · 1993Unverified

Iseki TA550

Name: Iseki TA550
Brand: Iseki

Iseki TA550 — Compact Utility tractor · 52 hp. Reference specifications; pending source verification.

The Iseki TA550 is a tractor with a power output of approximately 52 hp, positioning it within the lighter category of its class. This model was in production from 1993 to 1999. It features a 4-cylinder diesel liquid-cooled engine, coupled with four-wheel drive and a 16-speed gearbox. The operating weight of the tractor ranges from 3902 to 4696 pounds and supports operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

52 hp

Weight

3902 to 4696 pounds

Catalogue coverage

Variants represented

Richest spec table

48 rows

Recorded power

52 hp

Recorded weight

1769 kg

Transmissions

16-speed shuttle

Production years

1993-1999

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerIsekiReference

Compact Utility tractorReference

Built in JapanReference

Two- or four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab available with air-conditioning.Reference

Engine

Isuzu 2.8L 4-cyl dieselReference

Fuel tank51.1 LReference

Engine39.0 kWReference

Isuzu 4JB1Reference

dieselReference

4-cylinderReference

liquid-cooled inlineReference

Displacement2.8 LReference

Bore/Stroke93 x 102 mmReference

Power39.0 kWReference

Rated RPM2500Reference

Torque166.7 NmReference

Torque RPM1600Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speed shuttleReference

TypeshuttleReference

Gears16 forward and reverseReference

Four gears in four ranges with synchronized shuttle.Reference

PTO & Hydraulics

Rear TypeII/IReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540/1000 (1.375)Reference

Dimensions

Wheelbase202 cmReference

Weight3902 to 4696 poundsReference

Front tire7.5x16Reference

2WD Rear tire14.9x28Reference

2WD Standard tires (ag)Front: 7.5x16. Rear: 14.9x28Reference

4WD Standard tires (ag)Front: 8.3x20. Rear: 14.9x28Reference

Length346 cmReference

Width154 cmReference

Height161 cmReference

Height (cab)238 cmReference

ROPS Weight1769 kgReference

Cab Weight2130 kgReference

Ground clearance36 cmReference

Front tread121 to 155 cmReference

Rear tread121 to 162 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
