Tractor · 1993Unverified
Iseki TA550
Iseki TA550 — Compact Utility tractor · 52 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
52 hp
Weight
3902 to 4696 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Built in JapanReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab available with air-conditioning.Reference
Engine
Isuzu 2.8L 4-cyl dieselReference
Fuel tank51.1 LReference
Engine39.0 kWReference
Isuzu 4JB1Reference
dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement2.8 LReference
Bore/Stroke93 x 102 mmReference
Power39.0 kWReference
Rated RPM2500Reference
Torque166.7 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed shuttleReference
TypeshuttleReference
Gears16 forward and reverseReference
Four gears in four ranges with synchronized shuttle.Reference
PTO & Hydraulics
Rear TypeII/IReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase202 cmReference
Weight3902 to 4696 poundsReference
Front tire7.5x16Reference
2WD Rear tire14.9x28Reference
2WD Standard tires (ag)Front: 7.5x16. Rear: 14.9x28Reference
4WD Standard tires (ag)Front: 8.3x20. Rear: 14.9x28Reference
Length346 cmReference
Width154 cmReference
Height161 cmReference
Height (cab)238 cmReference
ROPS Weight1769 kgReference
Cab Weight2130 kgReference
Ground clearance36 cmReference
Front tread121 to 155 cmReference
Rear tread121 to 162 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
