Tractor · Unverified
Iseki TD4450
Iseki TD4450 — Compact Utility tractor · 41 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
41 hp
Weight
3679 to 3965 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Open operator station. Two-post fixed ROPS available.Reference
Variants
Field Boss 43similar White modelReference
Engine
Isuzu 2.4L 4-cyl dieselReference
Fuel tank50.0 LReference
Engine35.8 kWReference
Isuzu C240Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke86 x 102 mmReference
Power35.8 kWReference
Air cleanerdryReference
Rated RPM2600Reference
Torque132.1 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
18-speed synchromeshReference
TypesynchromeshReference
Gears18 forward and 6 reverseReference
Clutch260mm dry discReference
Three gears, plus reverse in three ranges plus creeper range.Reference
PTO & Hydraulics
PTO (claimed)30.6 kWReference
Typeopen centerReference
Pump flow32.0 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)1646 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@2250Reference
Engine RPM1000@2250Reference
Dimensions
Wheelbase199 cmReference
Weight3679 to 3965 poundsReference
Front tire6.00-16Reference
2WD Rear tire12.4-32Reference
2WD Standard tires (ag)Front: 6.00-16. Rear: 12.4-32Reference
4WD Standard tires (ag)Front: 8.30-20. Rear: 12.4-32Reference
Length340 cmReference
Width154 cmReference
Height229 cmReference
Height (steering wheel)149 cmReference
2WD Weight1668 kgReference
4WD Weight1798 kgReference
Ground clearance41 cmReference
Clearance (drawbar)38 cmReference
2WD Front tread115 to 165 cmReference
4WD Front tread109 to 162 cmReference
Rear tread123 to 163 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
