Iseki TE4320
Iseki TE4320 — Compact Utility tractor · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
2910 to 3142 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Open operator station.Reference
Variants
TE4320T2WDReference
TE4320F4WDReference
Engine
Isuzu 1.5L 4-cyl dieselReference
Fuel tank40.1 LReference
Engine (gross)25.7 kWReference
Engine (net)23.6 kWReference
Isuzu 4FA1Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke76 x 82 mmReference
Power (net)23.6 kWReference
Power (gross)25.7 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity7.1 LReference
Exhaust valve clearance0.254 mmReference
Transmission
18-speed synchromeshReference
TypesynchromeshReference
Gears18 forward and 6 reverseReference
Oil capacity45.0 LReference
Three gears (1-3), plus reverse (R), in three ranges (L/M/H) with additional creeper range.Reference
PTO & Hydraulics
Pressure142.0 barReference
Total flow29.1 lpmReference
Steering flow12.5 lpmReference
Rear TypeIReference
Rear lift (at ends)1230 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase180 cmReference
Weight2910 to 3142 poundsReference
Front tire6.00-16Reference
2WD Rear tire12.4-28Reference
2WD Standard tires (ag)Front: 6.00-16. Rear: 12.4-28Reference
4WD Standard tires (ag)Front: 8-18. Rear: 12.4-28Reference
Length320 cmReference
Width150 cmReference
Height199 cmReference
2WD Weight1319 kgReference
4WD Weight1425 kgReference
Ground clearance36 cmReference
2WD Front tread115 to 154 cmReference
4WD Front tread120 cmReference
Rear tread114 to 150 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps35Reference
Battery volts12Reference
Battery AH80Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
