Tractor · 1995Unverified
Iseki TF15F
Iseki TF15F — Sial Series · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
669 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Four-wheel driveReference
Two-post ROPS with canopy. Cab optional. Two-post folding ROPS on TF15NF.Reference
Variants
TF15F-UutilityReference
TF15HFhigh-cropReference
TF15NFnarrowReference
Engine
Iseki 0.9L 3-cyl dieselReference
Fuel tank20.1 LReference
Engine11.4 kWReference
Iseki E390Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.9 LReference
Power11.4 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Image courtesy of Agro-EngineeringReference
Transmission
6-speedReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)10.3 kWReference
Rear PTO Type540 (1.375)Reference
Engine RPM524@2500Reference
Engine RPM730@2500Reference
Engine RPM1187@2500Reference
Dimensions
Wheelbase129 cmReference
Weight669 kgReference
Front tire5.00-12Reference
Rear tire8-18Reference
Standard tires (ag)Front: 5.00-12. Rear: 8-18Reference
TF15HF Optional tires (ag)Front: 6-12. Rear: 8.3-20Reference
TF15NF Optional tires (ag)Front: 5-12. Rear: 8-16Reference
Length249 cmReference
Width103 cmReference
Height186 cmReference
Ground clearance29 cmReference
Front tread83 cmReference
Rear tread80 to 94 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH45Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
