Tractor · 1995Unverified
Iseki TF19F
Iseki TF19F — Sial Series · 17 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
699 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Four-wheel driveReference
Two-post ROPS with canopy. Cab optional. Two-post folding ROPS on TF19NF.Reference
Variants
TF19F-UutilityReference
TF19HFhigh-cropReference
TF19NFnarrowReference
Engine
Iseki 1.1L 3-cyl dieselReference
Fuel tank20.1 LReference
Engine14.0 kWReference
Iseki E3112Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke78 x 78 mmReference
Power14.0 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speedReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)12.6 kWReference
Rear PTO Type540 (1.375)Reference
Engine RPM524@2500Reference
Engine RPM730@2500Reference
Engine RPM1187@2500Reference
Dimensions
Wheelbase136 cmReference
Weight699 kgReference
Front tire6.00-12Reference
Rear tire8.3-22Reference
Standard tires (ag)Front: 6.00-12. Rear: 8.3-22Reference
TF19NF Optional tires (ag)Front: 5.00-12. Rear: 8-18Reference
Length249 cmReference
Width108 cmReference
Height191 cmReference
Ground clearance32 cmReference
Front tread88 cmReference
Rear tread85 to 100 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH45Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
