Tractor · 2001Unverified
Iseki TF330
Iseki TF330 — Compact Utility tractor · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
879 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Four-wheel driveReference
Steeringpower assistReference
Differential mechanical wet disc brakesReference
Two-post ROPS.Reference
Engine
Iseki 1.5L 3-cyl dieselReference
Fuel tank23.1 LReference
Engine22.0 kWReference
Iseki E3CDReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke87 x 84 mmReference
Power22.0 kWReference
Air cleanerdry elementReference
Rated RPM2500Reference
Starter typeelectricReference
Oil capacity4.1 LReference
Coolant capacity7.1 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Rear TypeIReference
Rear lift (at ends)899 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Mid PTO Type2000Reference
Dimensions
Wheelbase164 cmReference
Weight879 kgReference
Front tire6-14Reference
Rear tire12.4-16Reference
Ag front6-14Reference
Ag rear12.4-16Reference
Lawn/turf front24x8.50-12Reference
Lawn/turf rear315x80D-16Reference
Length295 cmReference
Width141 cmReference
Height (steering wheel)137 cmReference
Height (ROPS)231 cmReference
Shipping weight879 kgReference
Ground clearance16 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH55Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
