Tractor · Unverified
Iseki TG273N
Iseki TG273N — ???? - 2004 TG SeriesOrchard/Vineyard tractor · 27 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
27 hp
Weight
1190 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Orchard/Vineyard tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS.Reference
Variants
TG273utilityReference
TG273NnarrowReference
Engine
Iseki 1.5L 3-cyl dieselReference
Fuel tank35.0 LReference
Engine19.9 kWReference
Iseki E3CDReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Power19.9 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
Gears16 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear PTO Type600/797/1094/1292 (1.375)Reference
Dimensions
Wheelbase156 cmReference
Weight1190 kgReference
Front tire6-12Reference
Rear tire9.5-22Reference
Standard tires (ag)Front: 6-12. Rear: 9.5-22Reference
Length296 cmReference
Width133 cmReference
Height184 cmReference
Ground clearance299 cmReference
Front tread99 cmReference
Rear tread101 to 117 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
