Tractor · Unverified
Iseki TG333
Iseki TG333 — ???? - 2004 TG SeriesCompact Utility tractor · 31 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
31 hp
Weight
1529 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockrear standardReference
Power steeringReference
Two-post ROPS.Reference
Engine
Iseki 1.5L 3-cyl dieselReference
Fuel tank34.8 LReference
Engine24.6 kWReference
IsekiReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Power24.6 kWReference
Rated RPM2800Reference
Starter typeelectricReference
Transmission
16-speed shuttleReference
TypeshuttleReference
Gears16 forward and reverseReference
PTO & Hydraulics
PTO (claimed)23.1 kWReference
Pump flow29.1 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear PTO Type540Reference
Dimensions
Wheelbase178 cmReference
Weight1529 kgReference
Front tire8-16Reference
Rear tire13.6-24Reference
Ag front8-16Reference
Ag rear13.6-24Reference
Length314 cmReference
Width146 cmReference
Height199 cmReference
Ground clearance38 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
