Tractor · Unverified
Iseki TG413
Iseki TG413 — ???? - 2004 TG SeriesCompact Utility tractor · 40 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
3858 to 4189 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Engine
Iseki 2.4L 4-cyl dieselReference
Fuel tank54.9 LReference
Engine30.1 kWReference
Iseki E4DBReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Power30.1 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
Gears16 forward and reverseReference
Clutchwet discReference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear PTO Type577/716/1038/1298 (1.375)Reference
Dimensions
Wheelbase199 cmReference
Weight3858 to 4189 poundsReference
Front tire8-18Reference
Rear tire13.6-28Reference
Standard tires (ag)Front: 8-18. Rear: 13.6-28Reference
Length357 cmReference
Width152 cmReference
Height231 cmReference
ROPS Weight1749 kgReference
Cab Weight1900 kgReference
Ground clearance36 cmReference
Front tread124 cmReference
Rear tread114 to 150 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
