Tractor · Unverified

Iseki TG503

Name: Iseki TG503
Brand: Iseki

Iseki TG503 — ???? - 2004 TG SeriesCompact Utility tractor · 49 hp. Reference specifications; pending source verification.

The Iseki TG503 is a tractor with a rated power output of 49 hp, categorising it at the lower end of its class. It is equipped with a 4-cylinder diesel liquid-cooled engine, paired with a four-wheel drive system and a 16-speed gearbox. The tractor has a listed operating weight of 4023 to 4354 pounds, and is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

49 hp

Weight

4023 to 4354 pounds

Catalogue coverage

Variants represented

Richest spec table

39 rows

Recorded power

49 hp

Recorded weight

1824 kg

Transmissions

16-speed

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerIsekiReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post ROPS. Cab optional.Reference

Engine

Iseki 2.8L 4-cyl dieselReference

Fuel tank54.9 LReference

Engine36.8 kWReference

Iseki E4DDReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.8 LReference

Power36.8 kWReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speedReference

Gears16 forward and reverseReference

Clutchwet discReference

PTO & Hydraulics

Rear TypeIReference

Controlposition controlReference

Rear PTO Type577/716/1026 (1.375)Reference

Dimensions

Wheelbase199 cmReference

Weight4023 to 4354 poundsReference

Front tire8-18Reference

Rear tire13.6-28Reference

Standard tires (ag)Front: 8-18. Rear: 13.6-28Reference

Length357 cmReference

Width156 cmReference

Height234 cmReference

ROPS Weight1824 kgReference

Cab Weight1974 kgReference

Ground clearance37 cmReference

Front tread124 cmReference

Rear tread114 to 150 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
