Tractor · 2015Unverified
Iseki TG6400
Iseki TG6400 — TG6000 Series · 39 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
39 hp
Weight
3053 to 3384 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Built in JapanReference
Four-wheel driveReference
Differential lockstandardReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
Iseki 1.5L 3-cyl dieselReference
Fuel tank40.1 LReference
Engine (gross)28.7 kWReference
Iseki E3CDTReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Power (gross)28.7 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Rear valves2Reference
Pump flow47.7 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)1270 kgReference
Rear lift (at 24"/610mm)1149 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase177 cmReference
Weight3053 to 3384 poundsReference
Length307 cmReference
Width154 cmReference
Height (ROPS)257 cmReference
Height (cab)227 cmReference
ROPS Shipping weight1384 kgReference
Cab Shipping weight1534 kgReference
Electrical
Charging systemalternatorReference
Battery CCA582Reference
Battery volts12Reference
Battery AH55Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
