Tractor · 2001Unverified

Iseki TK532

Name: Iseki TK532
Brand: Iseki

Iseki TK532 — TK Series · 34 hp. Reference specifications; pending source verification.

The Iseki TK532 is a tractor with a rated power output of 34 hp, positioning it at the lighter end of its class. It was manufactured in 2001. The TK532 features a 3-cylinder diesel liquid-cooled engine and four-wheel drive, paired with a 16-speed gearbox. Its operating weight is listed as 1159 kg, suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

34 hp

Weight

1159 kg

Catalogue coverage

Variants represented

Richest spec table

58 rows

Recorded power

34 hp

Recorded weight

1159 kg

Transmissions

16-speed mechanical shuttle

Production years

2001-2001

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerIsekiReference

Compact Utility tractorReference

Four-wheel driveReference

Differential lockmechanical rearReference

Steeringpower assistReference

Mechanical wet disc brakesReference

Open operator station. Cab available.Reference

Engine

Iseki 1.5L 3-cyl dieselReference

Engine (gross)25.4 kWReference

Engine (net)23.6 kWReference

Iseki E3CDReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke87 x 84 mmReference

Power (net)23.6 kWReference

Power (gross)25.4 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Oil capacity4.7 LReference

Intake valve clearance0.356 mmReference

Exhaust valve clearance0.356 mmReference

Transmission

16-speed mechanical shuttleReference

Typemechanical shuttleReference

Gears16 forward and reverseReference

Oil capacity25.0 LReference

Capacities

Fuel29.9 LReference

Steering0.3 LReference

PTO & Hydraulics

Typeopen centerReference

Pressure132.1 barReference

Total flow36.7 lpmReference

Steering flow22.7 lpmReference

Steering cap.0.3 LReference

Rear TypeIReference

Controlposition control with available draft controlReference

Rear lift (at ends)1300 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase172 cmReference

Weight1159 kgReference

Front tire7x16Reference

Rear tire12.4x24Reference

Ag front7x16Reference

Ag rear12.4x24Reference

Lawn/turf front29x12.00-15Reference

Lawn/turf rear475/65D-20Reference

Length302 cmReference

Width135 cmReference

Height (steering wheel)145 cmReference

Shipping weight1159 kgReference

Ground clearance30 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps40Reference

Battery volts12Reference

Battery AH65Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
