Tractor · 2008Unverified
Iseki TK546
Iseki TK546 — Compact Utility tractor · 46 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
46 hp
Weight
1754 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Steeringhydrostatic powerReference
Mechanical wet disc brakesReference
Engine
Iseki 2.2L 4-cyl dieselReference
Engine34.3 kWReference
Iseki E4CGReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke87 x 92 mmReference
Power34.3 kWReference
Starter typeelectricReference
Oil capacity8.0 LReference
Intake valve clearance0.356 mmReference
Exhaust valve clearance0.356 mmReference
Transmission
16-speedReference
Gears16 forward and reverseReference
Oil capacity33.0 LReference
Capacities
Fuel48.1 LReference
Steering0.3 LReference
PTO & Hydraulics
Pressure156.9 barReference
Total flow29.1 lpmReference
Steering flow20.4 lpmReference
Steering cap.0.3 LReference
Rear TypeIReference
Rear lift (at ends)1399 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Weight1754 kgReference
Front tire7.5x16Reference
Rear tire13.6x28Reference
Ag front7.5x16Reference
Ag rear13.6x28Reference
Lawn/turf front26x12-15Reference
Lawn/turf rear475/65D-20Reference
Length355 cmReference
Width183 cmReference
Height (ROPS)216 cmReference
Shipping weight1754 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps60Reference
Battery volts12Reference
Battery AH95Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
