Iseki TM223
Iseki TM223 — ???? - 2004 TM SeriesCompact Utility tractor · 19 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
19 hp
Weight
640 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Differential mechanical dry shoe brakesReference
Engine
Iseki 1.1L 3-cyl dieselReference
Fuel tank23.1 LReference
Engine16.8 kWReference
Iseki E3112Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke78 x 78 mmReference
Power16.8 kWReference
Air cleanerdry elementReference
Compression22.5:1Reference
Rated RPM2800Reference
Firing order1-2-3Reference
StarterelectricReference
Starter volts12Reference
Oil capacity2.7 LReference
Coolant capacity7.1 LReference
Intake valve clearance0.254 mmReference
Exhaust valve clearance0.254 mmReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
PTO (claimed)13.8 kWReference
Typeopen centerReference
Pressure137.3 barReference
Total flow20.1 lpmReference
Steering flow9.8 lpmReference
Rear TypeIReference
Rear lift (at ends)550 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Mid PTO Type2000Reference
Dimensions
Wheelbase151 cmReference
Weight640 kgReference
Front tire5.00-12Reference
Rear tire9.5-16Reference
Ag front5.00-12Reference
Ag rear9.5-16Reference
Lawn/turf front23.0x10.5-12Reference
Lawn/turf rear315/75D-15Reference
Length267 cmReference
Width121 cmReference
Height (steering wheel)130 cmReference
Ground clearance27 cmReference
640 kgReference
Max front axle650 kgReference
Max rear axle749 kgReference
Iseki TM223 attachments
51.2" front-mount mower deckReference
54" mid-mount mower deckReference
60" mid-mount mower deckReference
42.1" rear-mount mower deckReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery CCA435Reference
Battery volts12Reference
Attachment overview
51.2" front-mount mower deckReference
54" mid-mount mower deckReference
60" mid-mount mower deckReference
42.1" rear-mount mower deckReference
Capacities
Max capacity1399 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
