Tractor · 2004Unverified
Iseki TM3240
Iseki TM3240 — TM Series · 19 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
19 hp
Weight
1521 to 1565 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Sub-Compact Utility tractorReference
Four-wheel driveReference
Differential lockstandardReference
Steeringhydrostatic powerReference
Mechanical wet disc brakesReference
ROPSReference
Engine
Iseki 1.1L 3-cyl dieselReference
Fuel tank25.0 LReference
Engine16.2 kWReference
Iseki E3112Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke78 x 78 mmReference
Power16.2 kWReference
Air cleanerdry elementReference
Compression22.5:1Reference
Rated RPM2600Reference
Firing order1-3-2Reference
StarterelectricReference
Starter volts12Reference
Oil capacity2.7 LReference
Coolant capacity7.1 LReference
Intake valve clearance0.254 mmReference
Exhaust valve clearance0.254 mmReference
Transmission
6-speedReference
Gears6 forward and 2 reverseReference
Oil capacity14.0 LReference
TransmissionhydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)13.8 kWReference
Pressure137.4 barReference
Total flow20.4 lpmReference
Steering flow9.8 lpmReference
Steering press.103.0 barReference
Rear Type1Reference
Rear lift (at ends)539 kgReference
Rear PTO Type567 (gear)Reference
Rear PTO Type587 (hydro)Reference
Mid PTO Type2000Reference
Dimensions
Wheelbase151 cmReference
Weight1521 to 1565 poundsReference
Front tire5.00-12Reference
Rear tire9.5-16Reference
Ag front5.00-12Reference
Ag rear9.5-16Reference
Lawn/turf front23.0x10.50-12Reference
Lawn/turf rear315/75D-15Reference
Length267 cmReference
Width122 cmReference
Ground clearance27 cmReference
Ground clearance28 cmReference
689 kgReference
709 kgReference
Max front axle650 kgReference
Max rear axle749 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery CCA435Reference
Battery volts12Reference
Capacities
Max capacity1399 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
