Tractor · 2010Unverified
Iseki TM3245
Iseki TM3245 — TM Series · 17 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
825 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockstandardReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post ROPS.Reference
Engine
Iseki 1.1L 3-cyl dieselReference
Fuel tank28.0 LReference
Engine16.6 kWReference
Iseki E3112Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke78 x 78 mmReference
Power16.6 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed gearReference
hydrostaticReference
TypegearReference
Gears8 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
PTO (claimed)12.9 kWReference
Typeopen centerReference
Pump flow20.9 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift600 kgReference
Rear PTOindependent (hydro)Reference
Clutchmechanical (gear)Reference
Clutchelectro-hydraulic (hydro)Reference
Rear PTO Type540 (1.375)Reference
Engine RPM567@2600 (gear)Reference
Engine RPM571@2600 (hydro)Reference
Mid PTO Type2000Reference
Engine RPM2032@2600 (gear)Reference
Engine RPM2129@2600 (hydro)Reference
Dimensions
Wheelbase156 cmReference
Weight825 kgReference
Front tire6-12Reference
Rear tire9.5-18Reference
Ag front6-12Reference
Ag rear9.5-18Reference
Lawn/turf front24x8.50-12Reference
Lawn/turf rear315/75D-15Reference
Length280 cmReference
Width110 cmReference
Ground clearance24 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
