Tractor · 1996Unverified
Iseki TR55
Iseki TR55 — TR Series · 54 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
54 hp
Weight
2390 kg
Hover a source tag to verify
Overview
DistributorIsekiReference
ManufacturerLandiniReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Cab standard with air-conditioning. Two-post ROPS available.Reference
Engine
Perkins 3.0L 4-cyl dieselReference
Fuel tank51.9 LReference
Engine40.4 kWReference
Perkins 704-30Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.0 LReference
Bore/Stroke97 x 100 mmReference
Power40.4 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
20-speedReference
Gears20 forward and reverseReference
Four in three standard ranges, plus two creeper ranges, with shuttle.Reference
PTO & Hydraulics
Rear TypeII/IReference
Rear PTO Type540 (1.375)Reference
Engine RPM580@2600Reference
Engine RPM827@2600Reference
Dimensions
Wheelbase200 cmReference
Weight2390 kgReference
Front tire8.3/8R24Reference
Rear tire12.4-32Reference
Standard tires (ag)Front: 8.3/8R24. Rear: 12.4-32Reference
Length366 cmReference
Width167 cmReference
Height235 cmReference
Ground clearance40 cmReference
Front tread121 to 161 cmReference
Rear tread122 to 186 cmReference
Speeds
With 12.4-32 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
