Tractor · 1996Unverified
Iseki TR63
Iseki TR63 — TR Series · 62 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
62 hp
Weight
2409 kg
Hover a source tag to verify
Overview
DistributorIsekiReference
ManufacturerLandiniReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Cab standard with air-conditioning. Two-post ROPS available.Reference
Engine
Perkins 3.0L 4-cyl dieselReference
Fuel tank51.9 LReference
Engine46.3 kWReference
Perkins 704-30Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.0 LReference
Bore/Stroke97 x 100 mmReference
Power46.3 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
20-speedReference
Gears20 forward and reverseReference
Four in three standard ranges, plus two creeper ranges, with shuttle.Reference
PTO & Hydraulics
Rear TypeII/IReference
Rear PTO Type540 (1.375)Reference
Engine RPM580@2600Reference
Engine RPM827@2600Reference
Engine RPM1090@2600Reference
Engine RPM-545@2600Reference
Dimensions
Wheelbase200 cmReference
Weight2409 kgReference
Front tire8.3/8R24Reference
Rear tire12.4-32Reference
Standard tires (ag)Front: 8.3/8R24. Rear: 12.4-32Reference
Length366 cmReference
Width167 cmReference
Height235 cmReference
Ground clearance40 cmReference
Front tread121 to 161 cmReference
Rear tread122 to 186 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Battery AH88Reference
Speeds
With 12.4-32 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
