Tractor · Unverified
Iseki TS3910
Iseki TS3910 — Compact Utility tractor · 39 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
39 hp
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Four-wheel driveReference
Open operator station.Reference
Engine
Iseki 1.5L 3-cyl dieselReference
Fuel tank29.9 LReference
Engine28.7 kWReference
Iseki 3AD1Reference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke86 x 86 mmReference
Power28.7 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
9-speed gearReference
18-speed creeperReference
TypegearReference
Gears9 forward and 3 reverseReference
TypecreeperReference
Gears18 forward and 6 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM630@2600Reference
Engine RPM773@2600Reference
Engine RPM990@2600Reference
Engine RPM1547@2600Reference
Dimensions
Wheelbase178 cmReference
Front tire6.00-16Reference
Rear tire12.4/11-24Reference
Ag front6.00-16Reference
Ag rear12.4/11-24Reference
Length310 cmReference
Width148 cmReference
Height199 cmReference
Ground clearance32 cmReference
Front tread112 cmReference
Rear tread114 to 143 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
