Tractor · 1982Unverified
Iseki TS4510
Iseki TS4510 — Compact Utility tractor · 39 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
39 hp
Weight
1650 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Mechanical drum brakesReference
Open operator station. Two-post fixed ROPS available.Reference
Engine
Isuzu 1.8L 3-cyl dieselReference
Fuel tank30.3 LReference
Engine33.6 kWReference
Isuzu 3AB1Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke86 x 102 mmReference
Power33.6 kWReference
Air cleanerdryReference
Compression20:1Reference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity6.3 LReference
Coolant capacity7.9 LReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutch225mm dry discsReference
Oil capacity16.3 LReference
PTO & Hydraulics
PTO (claimed)29.1 kWReference
Typeopen centerReference
Pressure147.1 barReference
Pump flow20.4 lpmReference
Rear lift1000 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase180 cmReference
Weight1650 kgReference
Front tire8.00-16Reference
Rear tire14.9-24Reference
Standard tires (ag)Front: 8.00-16. Rear: 14.9-24Reference
Length310 cmReference
Width154 cmReference
Height (hood)130 cmReference
Ground clearance40 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Battery AH96Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
