Tractor · 1984Unverified
Iseki TU1501
Iseki TU1501 — TU-01 Series · 15 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
1157 to 1235 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Variants
TU1501F4WDReference
Engine
Mitsubishi 0.8L 3-cyl dieselReference
Fuel tank16.7 LReference
Engine11.0 kWReference
Mitsubishi K3BReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.8 LReference
Bore/Stroke68 x 78 mmReference
Power11.0 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity16.5 LReference
Oil capacity3.0 LReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Oil capacity12.0 LReference
PTO & Hydraulics
Rear TypeJIS0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM513@2600Reference
Engine RPM759@2600Reference
Engine RPM1229@2600Reference
Dimensions
Wheelbase123 cmReference
Weight1157 to 1235 poundsReference
Front tire4.50-10Reference
2WD Rear tire8-18Reference
2WD Standard tires (ag)Front: 4.50-10. Rear: 8-18Reference
4WD Standard tires (ag)Front: 5.00-12. Rear: 8-18Reference
Length213 cmReference
Width103 cmReference
Height (exhaust)169 cmReference
2WD Weight524 kgReference
4WD Weight560 kgReference
2WD Ground clearance28 cmReference
4WD Ground clearance24 cmReference
2WD Front tread70/80 cmReference
4WD Front tread76 cmReference
Rear tread80/90 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
