Tractor · 1981Unverified
Iseki TU1600
Iseki TU1600 — TU Series · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
1168 to 1235 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Built in JapanReference
Two- or four-wheel driveReference
Open operator station.Reference
Variants
TU1600F4WDReference
Engine
Mitsubihi 0.9L 3-cyl dieselReference
Fuel tank16.7 LReference
Engine12.2 kWReference
Mitsubihi K3CReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.9 LReference
Bore/Stroke70 x 78 mmReference
Power12.2 kWReference
Rated RPM2600Reference
Torque51.9 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity3.0 LReference
Coolant capacity4.7 LReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Oil capacity12.0 LReference
PTO & Hydraulics
Rear PTO Type540 (1.375)Reference
Engine RPM513@2600Reference
Engine RPM759@2600Reference
Engine RPM1229@2600Reference
Dimensions
Wheelbase123 cmReference
Weight1168 to 1235 poundsReference
Front tire4.00-12Reference
2WD Rear tire8-18Reference
2WD Standard tires (ag)Front: 4.00-12. Rear: 8-18Reference
4WD Standard tires (ag)Front: 5.00-12. Rear: 8-18Reference
Length213 cmReference
Width103 cmReference
Height (exhaust)169 cmReference
2WD Weight529 kgReference
4WD Weight560 kgReference
2 WD Ground clearance35 cmReference
4WD Ground clearance25 cmReference
2WD Front tread70 cmReference
4WD Front tread76 cmReference
Rear tread80 to 91 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
