Tractor · 1984Unverified
Iseki TU1601
Iseki TU1601 — TU-01 Series · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
1168 to 1236 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Variants
TU1601F4WDReference
Engine
Mitsubishi 0.9L 3-cyl dieselReference
Fuel tank16.7 LReference
Engine12.2 kWReference
Mitsubishi K3CReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.9 LReference
Bore/Stroke70 x 78 mmReference
Power12.2 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity16.5 LReference
Oil capacity3.0 LReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Oil capacity12.0 LReference
PTO & Hydraulics
Rear TypeJIS0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM513@2600Reference
Engine RPM759@2600Reference
Engine RPM1229@2600Reference
Dimensions
Wheelbase128 cmReference
Weight1168 to 1236 poundsReference
Front tire4.50-10Reference
2WD Rear tire8-18Reference
2WD Standard tires (ag)Front: 4.50-10. Rear: 8-18Reference
4WD Standard tires (ag)Front: 5.00-12. Rear: 8-18Reference
Length213 cmReference
Width128 cmReference
Height (exhaust)169 cmReference
2WD Weight529 kgReference
4WD Weight560 kgReference
2WD Ground clearance28 cmReference
4WD Ground clearance24 cmReference
2WD Front tread70 cmReference
4WD Front tread76 cmReference
Rear tread80/90 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
