Tractor · 1984Unverified
Iseki TU240
Iseki TU240 — Landhope TU Series · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
1984 to 2205 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Open operator station.Reference
Variants
TU240F4WDReference
Engine
Iseki 1.3L 3-cyl dieselReference
Fuel tank25.0 LReference
Engine17.7 kWReference
Iseki E3AE1Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke80 x 86 mmReference
Power17.7 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
Three gears, plus reverse, in four ranges.Reference
PTO & Hydraulics
Rear Type0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM526@2500Reference
Engine RPM805@2500Reference
Engine RPM1244@2500Reference
Dimensions
Wheelbase152 cmReference
Weight1984 to 2205 poundsReference
Front tire500-15Reference
2WD Rear tire11.2-24Reference
2WD Standard tires (ag)Front: 500-15. Rear: 11.2-24Reference
4WD Standard tires (ag)Front: 7-16. Rear: 11.2-24Reference
Length307 cmReference
Width128 cmReference
2WD Height192 cmReference
4WD Height193 cmReference
2WD Weight899 kgReference
4WD Weight1000 kgReference
2WD Ground clearance31 cmReference
4WD Ground clearance32 cmReference
2WD Front tread93 to 98 cmReference
4WD Front tread104 cmReference
Rear tread98/105/109/118/130 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
