Tractor · 1985Unverified
Iseki TX2140
Iseki TX2140 — Compact Utility tractor · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
1069 to 1168 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Original priceGBP4495 (1988 2WD )Reference
Original priceGBP5395 (1988 4WD )Reference
Two- or four-wheel driveReference
Manual steeringReference
Mechanical dry shoe brakesReference
Open operator station.Reference
Variants
TX2140F4WDReference
Engine
Mitsubishi 0.8L 3-cyl dieselReference
Fuel tank12.1 LReference
Engine10.4 kWReference
Mitsubishi K3AReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.8 LReference
Bore/Stroke65 x 78 mmReference
Power10.4 kWReference
Rated RPM2600Reference
Starter typeelectricReference
Oil capacity3.0 LReference
Exhaust valve clearance0.356 mmReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Oil capacity12.3 LReference
PTO & Hydraulics
Pressure124.1 barReference
Total flow10.2 lpmReference
Rear TypeJIS0Reference
Rear lift (at ends)380 kgReference
Rear PTO Type540 (1.375)Reference
Engine RPM454@2600Reference
Engine RPM724@2600Reference
Engine RPM1185@2600Reference
Dimensions
Wheelbase128 cmReference
Weight1069 to 1168 poundsReference
Front tire4.50x10Reference
Rear tire8x16Reference
2WD Ag front4.50x10Reference
4WD Ag front5.00x12Reference
Ag rear8x16Reference
Length195 cmReference
Width108 cmReference
2WD Weight484 kgReference
4WD Weight529 kgReference
4WD Ground clearance24 cmReference
2WD Ground clearance33 cmReference
Electrical
Charging systemalternatorReference
Charging amps35Reference
Battery volts12Reference
Battery AH45Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
