Tractor · 2015Unverified
Iseki Z15
Iseki Z15 — Sub-Compact Utility tractor · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
499 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Sub-Compact Utility tractorReference
Four-wheel driveReference
SteeringmanualReference
SteeringpowerReference
Mechanical wet disc brakesReference
Two-post folding ROPS with available canopy.Reference
Engine
Shibaura 0.8L 3-cyl dieselReference
Fuel tank12.9 LReference
Engine11.6 kWReference
Shibaura E673Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.8 LReference
Power11.6 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speedReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear PTOindependentReference
ClutchdryReference
Rear PTO Type540 (1.375)Reference
Engine RPM519@2700Reference
Engine RPM850@2700Reference
Dimensions
Wheelbase127 cmReference
Weight499 kgReference
Front tire5-12Reference
Rear tire8-16Reference
Standard tires (ag)Front: 5-12. Rear: 8-16Reference
Length202 cmReference
Width97 cmReference
Height (ROPS)196 cmReference
Ground clearance25 cmReference
Front tread78 cmReference
Rear tread72 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
