Lawn Tractor · 1977Unverified
Jacobsen 1450 53301
Jacobsen 1450 53301 — Garden tractor · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
371 kg
Hover a source tag to verify
Overview
ManufacturerJacobsen (a part of Textron)Reference
Garden tractorReference
Built in Racine, Wisconsin, USAReference
Original price was $3,200 in 1980Reference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
14HP Kohler 512cc 1-cyl gasolineReference
Fuel tank11.4 LReference
Kohler K321AQSReference
gasolineReference
1-cylinderReference
air-cooled horizontal-shaftReference
Displacement31.27 ciReference
Bore/Stroke89 x 83 mmReference
Power (gross)10.4 kWReference
Air cleanerdryReference
Rated RPM3600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity1.4 LReference
Transmission
hydrostaticReference
Typeshaft-driven hydrostaticReference
Gearsinfinite forward and infintie (2-range) reverse (2-range)Reference
PTO & Hydraulics
Rear Type0Reference
Typesleeve hitchReference
Rear PTOindependentReference
Rear PTO Type3300Reference
Front PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase116 cmReference
Weight371 kgReference
Front tire16x6.50-8Reference
Rear tire23x10.50-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x10.50-12Reference
Width111 cmReference
Height (steering wheel)106 cmReference
Height (hood)93 cmReference
Clearance (front axle)23 cmReference
Clearance (rear axle)20 cmReference
Jacobsen 1450 attachments
42" mid-mount mower deckReference
50" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
42" mid-mount mower deckReference
50" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
