Lawn Tractor · 1977Unverified
Jacobsen 80 53132
Jacobsen 80 53132 — Lawn tractor · 8 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
8 hp
Weight
185 kg
Hover a source tag to verify
Overview
ManufacturerJacobsenReference
Lawn tractorReference
Original price was $1,469 in 1979Reference
Two-wheel driveReference
Manual steeringReference
Mechanical disc brakesReference
Open operator station.Reference
Engine
8HP Briggs & Stratton 318cc 1-cyl gasolineReference
Fuel tank3.8 LReference
Briggs & Stratton 190000Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement19.44 ciReference
Bore/Stroke76 x 70 mmReference
Power (gross)6.0 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
3-speed gearReference
Typebelt-driven gearReference
Gears3 forward and 1 reverseReference
Clutchidler pulleyReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Dimensions
Wheelbase106 cmReference
Weight185 kgReference
Front tire13x5.0Reference
Rear tire18x8.50-8Reference
Lawn/turf front13x5.0Reference
Lawn/turf rear18x8.50-8Reference
Length147 cmReference
Width81 cmReference
Height (steering wheel)93 cmReference
Ground clearance13 cmReference
Jacobsen 80 attachments
34" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Charging amps3 (battery)Reference
Charging amps5 (lights)Reference
Battery volts12Reference
Battery AH22Reference
Attachment overview
34" mid-mount mower deckReference
SnowblowerReference
BladeReference
34" Mower deck
Typemid-mount JacobsenReference
Type2-blade with manual liftReference
Cutting width86 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
