Lawn Tractor · 1981Unverified

Jacobsen GT12G 34001

Name: Jacobsen GT12G 34001
Brand: Jacobsen

Jacobsen GT12G 34001 — Garden tractor · 12 hp. Reference specifications; pending source verification.

The Jacobsen GT12G 34001 lawn tractor features a 12 hp rating, typical of its mid-range category. It was manufactured between 1981 and 1986, and is equipped with a 1-cylinder petrol air-cooled engine, coupled with two-wheel drive and a 4-speed gearbox. The machine's operating weight is listed at 347 kg, and it is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

12 hp

Weight

347 kg

Catalogue coverage

Variants represented

Richest spec table

48 rows

Recorded power

12 hp

Recorded weight

347 kg

Transmissions

4-speed gear

Production years

1981-1986

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerJacobsenReference

Garden tractorReference

Two-wheel driveReference

Manual steeringReference

Mechanical band brakesReference

Open operator station.Reference

Engine

12HP Kohler 476cc 1-cyl gasolineReference

Fuel tank11.4 LReference

Kohler K301AQSReference

gasolineReference

1-cylinderReference

air-cooled horizontal-shaftReference

Displacement29.1 ciReference

Bore/Stroke86 x 83 mmReference

Power (gross)8.9 kWReference

StarterelectricReference

Starter volts12Reference

Oil capacity1.9 LReference

Oil change30 hReference

Transmission

4-speed gearReference

Typebelt-driven gearReference

Gears4 forward and 1 reverseReference

PTO & Hydraulics

Typesleeve hitchReference

Rear PTOindependentReference

Front PTOindependentReference

ClutchelectricReference

Dimensions

Wheelbase116 cmReference

Weight347 kgReference

Front tire16x6.50-8Reference

Rear tire23x8.50-12Reference

Lawn/turf front16x6.50-8Reference

Lawn/turf rear23x8.50-12Reference

Length185 cmReference

Width96 cmReference

Height (steering wheel)104 cmReference

Height (hood)93 cmReference

Clearance (front axle)23 cmReference

Clearance (rear axle)20 cmReference

Jacobsen GT12G attachments

42" mid-mount mower deckReference

snowblowerReference

bladeReference

Electrical

GroundnegativeReference

Charging amps15Reference

Battery volts12Reference

Battery AH22Reference

Attachment overview

42" mid-mount mower deckReference

SnowblowerReference

BladeReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
