Lawn Tractor · 1981Unverified
Jacobsen GT12G 34001
Jacobsen GT12G 34001 — Garden tractor · 12 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
12 hp
Weight
347 kg
Hover a source tag to verify
Overview
ManufacturerJacobsenReference
Garden tractorReference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
12HP Kohler 476cc 1-cyl gasolineReference
Fuel tank11.4 LReference
Kohler K301AQSReference
gasolineReference
1-cylinderReference
air-cooled horizontal-shaftReference
Displacement29.1 ciReference
Bore/Stroke86 x 83 mmReference
Power (gross)8.9 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity1.9 LReference
Oil change30 hReference
Transmission
4-speed gearReference
Typebelt-driven gearReference
Gears4 forward and 1 reverseReference
PTO & Hydraulics
Typesleeve hitchReference
Rear PTOindependentReference
Front PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase116 cmReference
Weight347 kgReference
Front tire16x6.50-8Reference
Rear tire23x8.50-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x8.50-12Reference
Length185 cmReference
Width96 cmReference
Height (steering wheel)104 cmReference
Height (hood)93 cmReference
Clearance (front axle)23 cmReference
Clearance (rear axle)20 cmReference
Jacobsen GT12G attachments
42" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Charging amps15Reference
Battery volts12Reference
Battery AH22Reference
Attachment overview
42" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
