The JCB Fastrac 1115 is a tractor model with a power output of approximately 115 horsepower, a figure typical for its class. Production of the Fastrac 1115 occurred between 1995 and 1996. It is equipped with a 6-cylinder turbocharged diesel liquid-cooled engine, linked to four-wheel drive and a hydrostatic transmission. Its listed operating weight is 5300 kg, suitable for operations covering 200–800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
115 hp
Weight
5300 kg
Catalogue coverage
Variants represented
2
Richest spec table
32 rows
Recorded power
115 hp
Recorded weight
5300 kg
Transmissions
36-speed
Production years
1995-1996
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerJCBReference
Four-wheel Drive (4WD) tractorReference
Drive4x4 4WDReference
Steeringhydrostatic powerReference
Dry disc brakesReference
cab with air conditioningReference
Engine
Perkins 6.0L 6-cyl dieselReference
Fuel tank219.9 LReference
Engine85.8 kWReference
Perkins 1000-6 HR1Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.0 LReference
Bore/Stroke100 x 127 mmReference
Power85.8 kWReference
Rated RPM2400Reference
Torque448.0 NmReference
Torque RPM1400Reference
Transmission
36-speedReference
Gears36 forward and 12 reverseReference
PTO & Hydraulics
Total flow74.2 lpmReference
Rear lift6301 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase277 cmReference
Weight5300 kgReference
Front tire480/70R28Reference
Rear tire480/70R28Reference
Ag front480/70R28Reference
Ag rear480/70R28Reference
Length515 cmReference
Height279 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
