Tractor · 1994Unverified
JCB Fastrac 185
JCB Fastrac 185 — Four-wheel Drive (4WD) tractor · 188 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
188 hp
Weight
6500 kg
Hover a source tag to verify
Overview
ManufacturerJCBReference
Four-wheel Drive (4WD) tractorReference
Drive4x4 4WDReference
Steeringpower assistReference
Pneumatic dry disc brakesReference
Cab standard with air conditioning.Reference
Engine
Cummins 5.9L 6-cyl dieselReference
Engine140.2 kWReference
Cummins 6 BTAReference
intercooled turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.9 LReference
Bore/Stroke102 x 120 mmReference
Power140.2 kWReference
Fuel systemdirect injectionReference
Air cleanerdual dry elementReference
Rated RPM2400Reference
Torque750.1 NmReference
Torque RPM1400Reference
Starter volts12Reference
Transmission
36-speed synchromeshReference
TypesynchromeshReference
Gears36 forward and 12 reverseReference
Six gears (1-6) in three ranges (low, medium, high) plus reverse range. Two-speed electro-hydraulic power shift. Two design speed options available, with 65 or 75 kph top speed.Reference
Capacities
Fuel280.1 LReference
PTO & Hydraulics
Hydraulic system60.0 LReference
Capacity60.0 LReference
Pressure210.0 barReference
Valves2Reference
Pump flow60.0 lpmReference
Pump flow76.8 lpmReference
Total flow78.7 lpmReference
Rear TypeIII/IIINReference
Controlelectronic draft controlReference
Rear lift (at ends)7001 kgReference
Front HitchIIReference
Front lift (at ends)3000 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540/1000 (1.375)Reference
Rear PTO Type540/1000 (1.75)Reference
Engine RPM540@1966Reference
Engine RPM1000@2196Reference
Front PTOindependentReference
Front PTO Type540/1000 (1.375)Reference
Front PTO Type540/1000 (1.75)Reference
Dimensions
Wheelbase299 cmReference
Weight6500 kgReference
Front tire520/70R30Reference
Rear tire520/70R30Reference
Ag front520/70R30Reference
Ag rear520/70R30Reference
Length576 cmReference
Width236 cmReference
Height (cab)297 cmReference
Ground clearance40 cmReference
Front tread187 cmReference
Rear tread187 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps95Reference
Batteries2Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
