Tractor · 1998Unverified

JCB Fastrac 2125

Name: JCB Fastrac 2125
Brand: JCB

JCB Fastrac 2125 — Four-wheel Drive (4WD) tractor · 138 hp. Reference specifications; pending source verification.

The JCB Fastrac 2125 is a high-powered tractor with a rated output of 138 hp, ranking it among the more powerful machines in its class. Manufactured between 1998 and 2004, the Fastrac 2125 features a 6-cylinder turbocharged diesel liquid-cooled engine, which powers four-wheel drive through a hydrostatic transmission. The tractor weighs 5930 kg, making it suitable for tasks involving areas of approximately 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

138 hp

Weight

5930 kg

Catalogue coverage

Variants represented

Richest spec table

32 rows

Recorded power

138 hp

Recorded weight

5930 kg

Transmissions

54-speed

Production years

1998-2004

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJCBReference

Four-wheel Drive (4WD) tractorReference

Drive4x4 4WDReference

Steeringhydrostatic powerReference

Dry disc brakesReference

cab with air conditioningReference

Engine

Perkins 6.0L 6-cyl dieselReference

Fuel tank219.9 LReference

Engine102.9 kWReference

Perkins 1000-6T HR2Reference

turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Displacement6.0 LReference

Bore/Stroke100 x 127 mmReference

Power102.9 kWReference

Rated RPM2300Reference

Torque588.1 NmReference

Torque RPM1400Reference

Transmission

54-speedReference

Gears54 forward and 18 reverseReference

PTO & Hydraulics

Total flow74.2 lpmReference

Rear lift5250 kgReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase277 cmReference

Weight5930 kgReference

Front tire480/70R30Reference

Rear tire480/70R30Reference

Ag front480/70R30Reference

Ag rear480/70R30Reference

Length508 cmReference

Height288 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
