Tractor · 2016Unverified
JCB Fastrac 8290
JCB Fastrac 8290 — Four-wheel Drive (4WD) tractor · 280 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
280 hp
Weight
11090 kg
Hover a source tag to verify
Overview
ManufacturerJCBReference
Four-wheel Drive (4WD) tractorReference
Drive4x4 4WDReference
Final drivesoutboard planetaryReference
Differential lockelectro-hydraulic front and rearReference
Disc brakesReference
Trailer brakespneumaticReference
Trailer brakeshydraulicReference
Cab standard with air-conditioning.Reference
Engine
AGCO Power 8.4L 6-cyl dieselReference
Engine (gross)208.8 kWReference
Engine (max)228.2 kWReference
AGCO Power 84AWFReference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.4 LReference
Bore/Stroke111 x 145 mmReference
Rated Power (gross)208.8 kWReference
Maximum Power (gross)228.2 kWReference
Fuel systemcommon railReference
Air cleanerdryReference
Torque1350.6 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
continuously variable transmissionReference
Typecontinuously variable transmissionReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
PTO (claimed)202.8 kWReference
Hydraulic system149.9 LReference
Capacity149.9 LReference
Pressure210.0 barReference
Rear valves3 or 4Reference
Front valves0 to 2Reference
Pump flow137.0 lpmReference
Pump flow177.9 lpmReference
SCV flow99.9 lpmReference
SCV flow140.0 lpmReference
Rear TypeIIIReference
Controlposition and draft controlReference
Rear lift9979 kgReference
Front HitchIIReference
Front lift3492 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type1000 (1.75)Reference
Engine RPM540@1570Reference
Engine RPM1000@1930Reference
Front PTOindependentReference
Front PTO Type1000 (1.375)Reference
Engine RPM1000@2030Reference
Capacities
Fuel599.9 LReference
Exhaust fluid (DEF)60.2 LReference
Dimensions
Wheelbase311 cmReference
Weight11090 kgReference
Front tire540/65R34Reference
Rear tire710/70R38Reference
Standard tires (ag)Front: 540/65R34. Rear: 710/70R38Reference
Optional tires (ag)Front: 540/65R38. Rear: 650/75R38Reference
Optional tires (ag)Front: 650/65R34. Rear: 900/50R42Reference
Industrial front440/80R34Reference
Industrial rear650/65R38Reference
Length564 cmReference
Width225 cmReference
Height (hood)151 cmReference
Height (cab)338 cmReference
Max weight15966 kgReference
Ground clearance46 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps200Reference
Batteries2Reference
Battery CCA950Reference
Battery volts12Reference
Battery AH110Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
