Tractor · 1918Unverified
J.I. Case 10-18
J.I. Case 10-18 — Crossmotor Series · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Max power
8.4 kW
Weight
1705 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Standard-tread tractorReference
Built in Racine, Wisconsin, USAReference
Total built9,051Reference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Engine
J.I. Case 3.9L 4-cyl keroseneReference
Fuel tank39.7 LReference
Aux. fuel7.6 LReference
Drawbar (claimed)7.5 kWReference
Belt (claimed)13.4 kWReference
Plows2 (14-inch)Reference
Drawbar (tested)8.4 kWReference
Belt (tested)13.5 kWReference
J.I. CaseReference
keroseneReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Rated RPM1050Reference
Starter typehand-crankReference
Coolant capacity34.1 LReference
Belt power (max)13.5 kWReference
Power at rated engine speed13.5 kWReference
Max power8.4 kWReference
Transmission
2-speed gearReference
ManufacturerJ.I. CaseReference
TypegearReference
Gears2 forward and 1 reverseReference
PTO & Hydraulics
PTO (tested)13.5 kWReference
Dimensions
Weight1705 kgReference
Front tire30x6Reference
Rear tire42x9Reference
Ag front30x6 steelReference
Ag rear42x9 steelReference
Length274 cmReference
Width132 cmReference
Height147 cmReference
Capacities
Diameter36 cmReference
Width13 cmReference
RPM1050Reference
Speed1193.60 meters/minReference
Test results
Kerosene 2-speed 2WDApril 7 - 15, 1920Link: Nebraska Tractor Test 3 fileReference
Belt fuel use (max)10.2 l/hourReference
PTO performanceReference
Fuel use10.2 l/hourReference
Drawbar performanceReference
Max pull784 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
