Tractor · 1958Unverified
J.I. Case 1010
J.I. Case 1010 — Agricultural Crawler tractor · 100 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
100 hp
Max power
39.5 kW
Weight
7758 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Agricultural Crawler tractorReference
Built in Churubusco, Indiana, USAReference
DrivecrawlerReference
Hydraulic disc brakesReference
Open operator station.Reference
Variants
1000industrial crawlerReference
1010ag crawlerReference
Engine
Continental 6.3L 4-cyl dieselReference
Engine (gross)74.6 kWReference
Plows6Reference
Drawbar (tested)39.5 kWReference
Continental JD-382Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement6.3 LReference
Bore/Stroke114 x 152 mmReference
Power (gross)74.6 kWReference
Air cleaneroil bathReference
Compression15.5:1Reference
Rated RPM2000Reference
Torque374.3 NmReference
Torque RPM1200Reference
StarterelectricReference
Starter volts24Reference
Max power39.5 kWReference
Transmission
4-speed power shiftReference
TransmissionTerramaticReference
Typepower shiftReference
Gears4 forward and reverseReference
Clutchhydraulic discReference
PTO & Hydraulics
Pump flow113.6 lpmReference
Dimensions
Wheelbase200 cmReference
Weight7758 kgReference
16-inch tracksReference
Length355 cmReference
Width193 cmReference
Height (steering wheel)184 cmReference
Operating weight7758 kgReference
Gauge152 cmReference
J.I. Case 1010 attachments
bladeReference
1010 Serial Numbers
19577100001Reference
19587100209Reference
19597101031Reference
FAQ: How to read a serial number table.Reference
J.I. Case 1010 Tracks
Width40 cmReference
Test results
Diesel 4-speed crawlerAugust 14 - 28, 1959Link: Nebraska Tractor Test 712 fileReference
Drawbar performanceReference
Fuel use23.8 l/hourReference
Gear 2 used for power test.Reference
Max pull6921 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
