Industrial Tractor · 2007Unverified
J.I. Case 1150K
J.I. Case 1150K — K Series · 130 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
130 hp
Weight
27858 to 29365 pounds
Hover a source tag to verify
Overview
ManufacturerJ.I. Case (a part of CNH)Reference
BulldozerReference
Built in Calhoun, Georgia, USAReference
DrivecrawlerReference
Final drivesplanetaryReference
Four-post ROPS. Cab available with air-conditioning.Reference
Engine
FPT 6.7L 6-cyl dieselReference
Engine (gross)96.9 kWReference
Engine (net)88.0 kWReference
FPT 667TAReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.7 LReference
Bore/Stroke104 x 132 mmReference
Power (net)88.0 kWReference
Power (gross)96.9 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Rated RPM2200Reference
Torque588.5 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts24Reference
Oil capacity16.4 LReference
Coolant capacity32.2 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
Capacities
Fuel246.0 LReference
PTO & Hydraulics
Hydraulic system98.4 LReference
Capacity98.4 LReference
Pressure195.1 barReference
Pump flow132.1 lpmReference
Dimensions
Weight27858 to 29365 poundsReference
TracksReference
Dozer length502 cmReference
Height (ROPS)284 cmReference
Height (cab)284 cmReference
Gauge177 cmReference
Gauge198 cmReference
Operating12636 kgReference
Operating13003 kgReference
Operating13319 kgReference
J.I. Case 1150K attachments
bladeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps65Reference
Batteries2Reference
Battery CCA700Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
