Tractor · 1971Unverified
J.I. Case 1370
J.I. Case 1370 · 143 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
143 hp
Max power
90.2 kW
Weight
11690 to 13170 pounds
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Built in Racine, Wisconsin, USAReference
Total built17,413Reference
Original price was $31,400 in 1978Reference
Two-wheel driveReference
Differential lockhydraulicReference
Power steeringReference
Differential hydraulic wet discs brakesReference
Cab standard. Four-post ROPS and open-station available.Reference
Engine
J.I. Case 8.3L 6-cyl dieselReference
Drawbar (tested)97.6 kWReference
J.I. Case 504BDTReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Power increased in 1973 with engine RPM increase to 2200.Reference
Displacement8.3 LReference
Bore/Stroke117 x 127 mmReference
Air cleanertwo-stage dryReference
Compression16.5:1Reference
Rated RPM2200Reference
Rated RPM2100 (early)Reference
Firing order1-5-3-6-2-4Reference
Starter volts12Reference
Oil capacity14.1 LReference
Coolant capacity39.7 LReference
Power at rated engine speed106.3 kWReference
Max power90.2 kWReference
Power at rated engine speed116.0 kWReference
Max power97.6 kWReference
Transmission
12-speed partial power shiftReference
Typepartial power shiftReference
Gears12 forward and 3 reverseReference
PTO & Hydraulics
PTO (tested)116.0 kWReference
Hydraulic system130.6 LReference
Typeopen centerReference
Typevariable flowReference
Capacity130.6 LReference
Pressure141.3 barReference
Valves2Reference
Pump flow75.7 lpmReference
Total flow106.0 lpmReference
Total flow181.7 lpmReference
Steering flow30.3 lpmReference
Rear TypeIII/IIReference
Rear PTOindependentReference
Rear PTO Type1000Reference
Power at rated PTO speed107.1 kWReference
Power at rated PTO speed116.6 kWReference
Capacities
Fuel302.8 LReference
Dimensions
Wheelbase266 cmReference
Weight11690 to 13170 poundsReference
Front tire10.00-16Reference
Rear tire18.4-38Reference
Ag front10.00-16Reference
Ag rear18.4-38Reference
Ag front9.50-20Reference
Ag front11.00-16Reference
Ag front14L-16.1Reference
Ag rear16.9-38Reference
Ag rear20.8-34Reference
Ag rear20.8-38Reference
Ag rear24.5-32Reference
Ag rear23.1-34Reference
Ag rear12.4-42Reference
Length462 cmReference
Width243 cmReference
Width304 cmReference
Height (ROPS)269 cmReference
Height (cab)294 cmReference
Ground clearance40 cmReference
Bar rear axle88 mmReference
Bar rear axle98 mmReference
Cab5973 kgReference
ROPS5302 kgReference
Ballasted9507 kgReference
1370 Serial Numbers
19718674001Reference
19728691801Reference
19738712001Reference
19748736601Reference
19758770001Reference
19768797501Reference
19778810601Reference
19788830001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Batteries2Reference
Battery CCA300Reference
Battery volts12Reference
Battery Group30HReference
Test results
NTTL 1102: diesel (2100 rpm) 12-speed 2WDReference
NTTL 1148: diesel (2200 rpm) 12-speed 2WDReference
Diesel (2100 rpm) 12-speed 2WDJune 10 - 19, 1972Link: Nebraska Tractor Test 1102 fileReference
PTO performanceReference
Fuel use36.3 l/hourReference
Fuel use35.2 l/hourReference
Drawbar performanceReference
Fuel use36.0 l/hourReference
Gear 3-Lo used for power test.Reference
Max pull7533 kgReference
Gear 1-Int used for pull test.Reference
Diesel (2200 rpm) 12-speed 2WDOctober 31 - November 7, 1973Link: Nebraska Tractor Test 1148 fileReference
Fuel use42.0 l/hourReference
Fuel use39.4 l/hourReference
Fuel use41.3 l/hourReference
Max pull7475 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
