Tractor · 1919Unverified

J.I. Case 15-27

Name: J.I. Case 15-27
Brand: J.I. Case

J.I. Case 15-27 — Crossmotor Series · 15 hp. Reference specifications; pending source verification.

The J.I. Case 15-27 is a compact tractor, boasting a 15 hp rating, and was produced from 1919 to 1924. Equipped with a 4-cylinder liquid-cooled engine, it features two-wheel drive with a 2-speed gearbox and has a listed weight of 2930 kg. This model is intended for tasks on areas of approximately 200 acres. Detailed specifications are available.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

15 hp

Max power

16.3 kW

Weight

2930 kg

Catalogue coverage

Variants represented

Richest spec table

48 rows

Recorded power

15 hp

Recorded weight

2930 kg

Transmissions

2-speed gear

Production years

1919-1924

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerJ.I. CaseReference

Standard-tread tractorReference

Built in Racine, Wisconsin, USAReference

Total built17,628Reference

Two-wheel driveReference

SteeringmanualReference

Open operator station. Optional canopy.Reference

Engine

J.I. Case 6.3L 4-cyl keroseneReference

Fuel tank75.7 LReference

Aux. fuel10.4 LReference

Drawbar (claimed)11.2 kWReference

Belt (claimed)20.1 kWReference

Plows3Reference

Drawbar (tested)16.3 kWReference

Belt (tested)23.3 kWReference

J.I. CaseReference

keroseneReference

4-cylinderReference

liquid-cooledReference

Displacement6.3 LReference

Bore/Stroke114 x 152 mmReference

Rated RPM900Reference

Starter typehand-crankReference

Coolant capacity41.6 LReference

Belt power (max)23.3 kWReference

Max power16.3 kWReference

Transmission

2-speed gearReference

ManufacturerJ.I. CaseReference

TypegearReference

Gears2 forward and 1 reverseReference

PTO & Hydraulics

Rear PTOtransmission (optional)Reference

Rear PTO Type540Reference

Dimensions

Weight2930 kgReference

Front tire32x6Reference

Rear tire52x14Reference

Ag front32x6 steelReference

Ag rear52x14 steelReference

Length322 cmReference

Width182 cmReference

Height172 cmReference

Capacities

Diameter40 cmReference

Width16 cmReference

RPM900Reference

Speed1146.66 meters/minReference

Test results

Kerosene 2-speed 2WDApril 2 - 30, 1920Link: Nebraska Tractor Test 4 fileReference

Belt fuel use (max)12.1 l/hourReference

Drawbar performanceReference

Max pull1560 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
