Industrial Tractor · 1987Unverified
J.I. Case 1550
J.I. Case 1550 — Bulldozer · 168 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
168 hp
Weight
15958 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
BulldozerReference
DrivecrawlerReference
Four-post ROPS. Cab optional with available air-conditioning.Reference
Engine
J.I. Case 8.3L 6-cyl dieselReference
Engine (gross)125.3 kWReference
Engine (net)111.9 kWReference
J.I. Case 6T-830Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.3 LReference
Bore/Stroke114 x 135 mmReference
Power (net)111.9 kWReference
Power (gross)125.3 kWReference
Air cleanerdryReference
Compression17.3:1Reference
Torque729.5 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts24Reference
Oil capacity22.7 LReference
Coolant capacity24.6 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity106.0 LReference
Capacities
Fuel287.7 LReference
PTO & Hydraulics
Hydraulic system78.3 LReference
Typeopen centerReference
Capacity78.3 LReference
Pressure172.4 barReference
Pump flow159.0 lpmReference
Dimensions
Weight15958 kgReference
22-inch tracksReference
Length378 cmReference
Dozer length629 cmReference
Outside Beam dozer length601 cmReference
Height (steering wheel)252 cmReference
Height (ROPS)318 cmReference
Operating weight15958 kgReference
Gauge187 cmReference
LGP Gauge198 cmReference
J.I. Case 1550 attachments
bladeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Charging volts24Reference
Batteries2Reference
Battery CCA950Reference
Battery volts12Reference
J.I. Case 1550 Tracks
Width55 cmReference
Length on ground238 cmReference
Area on ground2.7 m²Reference
Ground pressure0.6 barReference
Width60 cmReference
Length on ground187 cmReference
Area on ground2.9 m²Reference
Ground pressure0.5 barReference
LGP width55 cmReference
LGP length on ground269 cmReference
LGP area on ground3.0 m²Reference
LGP ground pressure0.5 barReference
LGP width60 cmReference
LGP area on ground3.3 m²Reference
LGP ground pressure0.5 barReference
LGP width91 cmReference
LGP area on ground4.9 m²Reference
LGP ground pressure0.3 barReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
