Tractor · 1976Unverified
J.I. Case 1570
J.I. Case 1570 — Row-Crop tractor · 180 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
180 hp
Max power
110.3 kW
Weight
13300 to 16000 pounds
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Row-Crop tractorReference
Built in Racine, Wisconsin, USAReference
Original price was $30,000 in 1978Reference
Two-wheel driveReference
Differential lockhydraulic rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
J.I. Case 8.3L 6-cyl dieselReference
Fuel tank302.8 LReference
Drawbar (tested)110.3 kWReference
J.I. CaseReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.3 LReference
Bore/Stroke117 x 127 mmReference
Fuel systemdirect injectionReference
Air cleanerdual stage dryReference
Compression15.8:1Reference
Rated RPM2100Reference
Starter volts12Reference
Coolant capacity41.6 LReference
Power at rated engine speed134.5 kWReference
Max power110.3 kWReference
Transmission
12-speed three-speed power shiftReference
Typethree-speed power shiftReference
Gears12 forward and 3 reverseReference
Clutchhydraulic wet discReference
Four gears, plus reverse, with three-range power shift.Reference
PTO & Hydraulics
PTO (claimed)134.2 kWReference
PTO (tested)134.5 kWReference
Typeopen centerReference
Valves2 to 4Reference
Pump flow75.7 lpmReference
Pump flow151.4 lpmReference
Rear TypeIIIReference
Rear lift (at 24"/610mm)3594 kgReference
Rear PTOindependentReference
Rear PTO Type1000Reference
Engine RPM1000@2100Reference
Dimensions
Wheelbase269 cmReference
Weight13300 to 16000 poundsReference
Front tire11.00-16Reference
Rear tire18.4-38Reference
Ag front11.00-16Reference
Ag rear18.4-38Reference
Ag rear24.5-32Reference
Ag rear30.5-32Reference
Ag rear20.8-38Reference
Length469 cmReference
Height (cab)289 cmReference
Height (exhaust)322 cmReference
Bar rear axle88 mmReference
Bar rear axle98 mmReference
Front tread152 to 223 cmReference
Rear tread172 to 241 cmReference
Rear tread172 to 302 cmReference
Shipping6032 kgReference
Operating7257 kgReference
Ballasted9230 kgReference
1570 Serial Numbers
Location:Left side of the steering console.Reference
19768797501Reference
19778809950Reference
19788830001Reference
FAQ: How to read a serial number table.Reference
Test results
Diesel 12-speed 2WDAugust 27 - September 3, 1976Link: Nebraska Tractor Test 1218 fileReference
PTO performanceReference
Fuel use45.4 l/hourReference
Drawbar performanceReference
Fuel use43.9 l/hourReference
Gear 3L used for power test.Reference
Max pull7763 kgReference
Gear 2L used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
