Lawn Tractor · 1984Unverified
J.I. Case 210 XC
J.I. Case 210 XC — Garden tractor · 10 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
10 hp
Weight
254 kg
Hover a source tag to verify
Overview
DistributorJ.I. CaseReference
ManufacturerIngersollReference
Garden tractorReference
Built in Winneconne, Wisconsin, USAReference
Two-wheel driveReference
Manual steeringReference
Band brakesReference
Open operator station.Reference
Engine
10HP Kohler 391cc 1-cyl gasolineReference
Fuel tank11.4 LReference
Kohler K241Reference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement23.9 ciReference
Bore/Stroke83 x 73 mmReference
Power (gross)7.5 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
PTO & Hydraulics
Typesleeve hitchReference
Dimensions
Wheelbase116 cmReference
Weight254 kgReference
Front tire6.50-8Reference
Rear tire8.50-12Reference
Lawn/turf front6.50-8Reference
Lawn/turf rear8.50-12Reference
Length167 cmReference
Width95 cmReference
Height101 cmReference
Ground clearance18 cmReference
J.I. Case 210 XC attachments
38" mid-mount mower deckReference
44" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
44" mid-mount mower deckReference
SnowblowerReference
BladeReference
The 210XC could be fitted with the model K72 32-inch mechanical tiller.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
