Tractor · 1958Unverified
J.I. Case 211-B
J.I. Case 211-B — 200B Series · 31 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
31 hp
Max power
18.5 kW
Weight
1657 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Row-Crop tractorReference
Built in Rock Island, Illinois, USAReference
Total built1,641Reference
Original price was $2,500 in 1960Reference
Two-wheel driveReference
Steeringpower assistReference
Differential mechanical disc brakesReference
Open operator station.Reference
Variants
210-ButilityReference
211-Brow-cropReference
Engine
J.I. Case 2.1L 4-cyl gasolineReference
Fuel tank49.2 LReference
Drawbar (claimed)18.6 kWReference
Plows2Reference
Drawbar (tested)18.5 kWReference
J.I. CaseReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.1 LReference
Bore/Stroke79 x 105 mmReference
Fuel systemcarburetorReference
Air cleaneroil bathReference
Compression7.5:1Reference
Rated RPM1900Reference
Idle RPM500-2050Reference
Firing order1-3-4-2Reference
Starter volts6Reference
Oil capacity4.7 LReference
Coolant capacity11.4 LReference
Sparkplug gap0.635 mmReference
Intake valve clearance0.356 mmReference
Exhaust valve clearance0.356 mmReference
Power at rated engine speed23.0 kWReference
Max power18.5 kWReference
Transmission
4-speed gearReference
12-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
Clutch235mm dry discReference
Oil capacity26.5 LReference
TransmissionTripl-RangeReference
Gears12 forward and 3 reverseReference
PTO & Hydraulics
PTO (claimed)22.4 kWReference
PTO (tested)23.0 kWReference
Rear PTO Type540 (1.375)Reference
Engine RPM533@1750Reference
Power at rated PTO speed21.8 kWReference
Dimensions
Wheelbase201 cmReference
Weight1657 kgReference
Front tire5.00-15Reference
Rear tire10-28Reference
Ag front5.00-15Reference
Ag rear10-28Reference
Ag rear11-28Reference
Length317 cmReference
Width201 cmReference
Height (steering wheel)151 cmReference
Operating weight1657 kgReference
Ballasted weight2492 kgReference
Clearance (rear axle)49 cmReference
Front tread132 to 203 cmReference
Rear tread121 to 223 cmReference
J.I. Case 211-B attachments
front-end loaderReference
211-B Serial Number Location
Serial number plate on dashboard.Reference
Electrical
GroundpositiveReference
Charging systemgeneratorReference
Battery volts6Reference
Battery AH100Reference
Test results
Gasoline 4-speed 2WDMarch 19 - 25, 1959Link: Nebraska Tractor Test 688 fileReference
PTO performanceReference
Fuel use10.6 l/hourReference
Fuel use9.8 l/hourReference
Drawbar performanceReference
Fuel use9.5 l/hourReference
Gear 3 used for power test.Reference
Max pull1669 kgReference
Gear 1 used for pull test.Reference
Speeds
With 10-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
