Lawn Tractor · 1973Unverified

J.I. Case 224

Name: J.I. Case 224
Brand: J.I. Case

J.I. Case 224 — 200 Series · 14 hp. Reference specifications; pending source verification.

The J.I. Case 224 is a lawn tractor model with a rated power output of 14 hp, a mid-range figure for its class. Production of the model spanned the period from 1973 to 1988. It is powered by a 1-cylinder petrol air-cooled engine and features two-wheel drive. The tractor's operating weight is listed as 324 kg, with an operational capacity of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

14 hp

Weight

324 kg

Catalogue coverage

Variants represented

Richest spec table

65 rows

Recorded power

14 hp

Recorded weight

324 kg

Production years

1973-1988

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerJ.I. CaseReference

Garden tractorReference

Built in Winneconne, Wisconsin, USAReference

Two-wheel driveReference

Band brakesReference

Open operator station.Reference

Engine

14HP Kohler 512cc 1-cyl gasolineReference

Kohler K321ASReference

gasolineReference

1-cylinderReference

air-cooledReference

Displacement31.27 ciReference

Bore/Stroke89 x 83 mmReference

Power10.4 kWReference

Compression7:1Reference

Rated RPM3600Reference

Starter volts12Reference

Sparkplug gap0.889 mmReference

Point gap0.508 mmReference

Intake valve clearance0.229 mmReference

Exhaust valve clearance0.508 mmReference

Oil capacity1.4 LReference

Transmission

hydraulic driveReference

TransmissionHy-DriveReference

Typehydraulic driveReference

Gearsinfinite forward and reverse (2-range)Reference

Oil capacity6.2 LReference

Oil type[0oC]Reference

32oF [0oC]↑: SAE20W40Reference

32oF [0oC]↓: SAE5W20Reference

Capacities

Fuel11.4 LReference

PTO & Hydraulics

Hydraulic system5.7 LReference

Typeopen centerReference

Capacity5.7 LReference

Pressure137.9 barReference

Pump flow30.3 lpmReference

Typesleeve hitchReference

Dimensions

Wheelbase116 cmReference

Weight324 kgReference

Front tire6.50-8Reference

Rear tire8.00-16Reference

Lawn/turf front6.50-8Reference

Lawn/turf rear8.00-16Reference

Lawn/turf rear8.50-12Reference

Lawn/turf rear10.50-12Reference

Length165 cmReference

Width93 cmReference

Height (steering wheel)101 cmReference

Height (hood)90 cmReference

Shipping weight324 kgReference

Ground clearance18 cmReference

J.I. Case 224 attachments

38" mid-mount mower deckReference

48" mid-mount mower deckReference

snowblowerReference

bladeReference

224 Serial Numbers

Location:Serial number plate on dashboard, below steering column.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps15Reference

Battery volts12Reference

Battery AH24Reference

Attachment overview

38" mid-mount mower deckReference

48" mid-mount mower deckReference

SnowblowerReference

BladeReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
