Lawn Tractor · 1984Unverified
J.I. Case 226
J.I. Case 226 — 200 Series · 16 hp. Reference specifications; pending source verification.
The J.I. Case 226 lawn tractor has a rating of approximately 16 hp, a mid-range figure for its class. Produced between 1984 and 1988, this model is equipped with a 2-cylinder petrol air-cooled engine and two-wheel drive, with an operating weight of 278 kg. Its capabilities extend to operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
278 kg
Catalogue coverage
Variants represented
2
Richest spec table
50 rows
Recorded power
16 hp
Recorded weight
278 kg
Production years
1984-1988
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorJ.I. CaseReference
ManufacturerIngersollReference
Garden tractorReference
Built in Winneconne, Wisconsin, USAReference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
16HP Onan 709cc 2-cyl gasolineReference
Onan B43MReference
gasolineReference
2-cylinderReference
air-cooledReference
Displacement43.3 ciReference
Bore/Stroke83 x 67 mmReference
Power (gross)11.9 kWReference
Rated RPM3600Reference
Starter volts12Reference
Transmission
hydraulic driveReference
TransmissionHY-DriveReference
Typehydraulic driveReference
Gearsinfinite forward and reverseReference
Capacities
Fuel11.4 LReference
PTO & Hydraulics
Hydraulic system4.7 LReference
Typeopen centerReference
Capacity4.7 LReference
Typesleeve hitchReference
Dimensions
Wheelbase116 cmReference
Weight278 kgReference
Front tire6.50-8Reference
Rear tire8.50-12Reference
Lawn/turf front6.50-8Reference
Lawn/turf rear8.50-12Reference
Length167 cmReference
Width95 cmReference
Height101 cmReference
Ground clearance18 cmReference
J.I. Case 226 attachments
38" mid-mount mower deckReference
44" mid-mount mower deckReference
48" mid-mount mower deckReference
snowblowerReference
bladeReference
226 Serial Numbers
Location:Serial number plate on dashboard, below steering column.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
44" mid-mount mower deckReference
48" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
