Tractor · 1979Unverified
J.I. Case 2290
J.I. Case 2290 — 90 Series · 129 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
129 hp
Max power
79.1 kW
Weight
10080 to 13700 pounds
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Row-Crop tractorReference
Built in Racine, Wisconsin, USAReference
Original price$44,400 (1983)Reference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Differential hydraulic wet disc brakesReference
Four-post ROPS. Silent Guardian cab with air-conditioning.Reference
Engine
J.I. Case 8.3L 6-cyl dieselReference
Fuel tank246.0 LReference
Drawbar (claimed)81.3 kWReference
Drawbar (tested)81.4 kWReference
J.I. CaseReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.3 LReference
Bore/Stroke117 x 127 mmReference
Air cleanerdual paper elements with aspiratorReference
Compression15.75:1Reference
Rated RPM2100Reference
Starter volts12Reference
Coolant capacity36.0 LReference
Power at rated engine speed96.0 kWReference
Max power79.1 kWReference
Power at rated engine speed96.3 kWReference
Max power81.4 kWReference
Transmission
8-speedReference
12-speed partial power shiftReference
Gears8 forward and 4 reverseReference
Typepartial power shiftReference
Gears12 forward and 3 reverseReference
PTO & Hydraulics
PTO (claimed)96.2 kWReference
PTO (tested)96.3 kWReference
Typeclosed centerReference
Valves2Reference
Pump flow79.5 lpmReference
Rear TypeIIReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Weight10080 to 13700 poundsReference
Front tire10.00-16Reference
Rear tire18.4-34Reference
Ag front10.00-16Reference
Ag rear18.4-34Reference
Length445 cmReference
Height (cab)292 cmReference
Ground clearance40 cmReference
Rear axle88 by 2438 mmReference
Rear axle88 by 3048 mmReference
4572 kgReference
4640 kgReference
4717 kgReference
4785 kgReference
Operating6214 kgReference
Ballasted7185 kgReference
5200 kgReference
2600 kgReference
900 kgReference
1200 kgReference
11000 kgReference
14300 kgReference
19000 kgReference
J.I. Case 2290 attachments
front-end loaderReference
2290 Serial Numbers
Location:In cab, near door or rear windowReference
19788835504Reference
19798840001Reference
19809901001Reference
19819910025Reference
19829918830Reference
19839924700Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Test results
NTTL 1296: diesel 8-speed 2WDReference
NTTL 1297: diesel 12-speed 2WDReference
Diesel 8-speed 2WDNovember 7, 1978 - January 4, 1979Link: Nebraska Tractor Test 1296 fileReference
PTO performanceReference
Fuel use33.7 l/hourReference
Drawbar performanceReference
Fuel use32.2 l/hourReference
Gear 3L used for power test.Reference
Max pull5731 kgReference
Gear 1H used for pull test.Reference
Diesel 12-speed 2WDNovember , - January 4, 1979Link: Nebraska Tractor Test 1297 fileReference
Fuel use32.6 l/hourReference
Gear 3I used for power test.Reference
Max pull5782 kgReference
Gear 2L used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
