Tractor · 1924Unverified
J.I. Case 25-45
J.I. Case 25-45 — Crossmotor Series · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Max power
25.8 kW
Weight
4565 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Standard-tread tractorReference
Built in Racine, Wisconsin, USAReference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Engine
J.I. Case 10.5L 4-cyl keroseneReference
Drawbar (claimed)18.6 kWReference
Belt (claimed)33.6 kWReference
Plows4-5 (14 inch)Reference
Drawbar (tested)25.8 kWReference
Belt (tested)39.2 kWReference
J.I. CaseReference
keroseneReference
4-cylinderReference
liquid-cooledReference
Displacement10.5 LReference
Bore/Stroke140 x 171 mmReference
Rated RPM850Reference
Starter typehand-crankReference
Image courtesy of Nico RoederReference
Belt power (max)39.2 kWReference
Max power25.8 kWReference
Transmission
2-speed gearReference
TransmissionJ.I. CaseReference
TypegearReference
Gears2 forward and 1 reverseReference
PTO & Hydraulics
Rear PTO Type540Reference
Dimensions
Weight4565 kgReference
Length388 cmReference
Width209 cmReference
Height228 cmReference
Capacities
Diameter41 cmReference
Width21 cmReference
RPM850Reference
Speed1118.31 meters/minReference
Test results
Kerosene 2-speed 2WDOctober 28 - November 9, 1924Link: Nebraska Tractor Test 110 fileReference
Belt fuel use (max)22.0 l/hourReference
Drawbar performanceReference
Max pull2608 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
