Tractor · 1912Unverified
J.I. Case 30-60
J.I. Case 30-60 — Standard-tread tractor · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
11702 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Standard-tread tractorReference
Built in Racine, Wisconsin, USAReference
Two-wheel driveReference
Final drivesspur gearReference
Manual steeringReference
Wooden platform with steel canopy.Reference
Engine
J.I. Case 30.9L 2-cyl keroseneReference
Fuel tank340.7 LReference
Aux. fuel83.3 LReference
Drawbar (claimed)22.4 kWReference
Belt (claimed)44.7 kWReference
J.I. CaseReference
keroseneReference
2-cylinderReference
liquid-cooledReference
Displacement30.9 LReference
Bore/Stroke254 x 305 mmReference
Rated RPM365Reference
Starter typehand-crankReference
Oil capacity9.5 LReference
Coolant capacity643.6 LReference
Transmission
1-speed gearReference
TransmissionJ.I. CaseReference
TypegearReference
Gears1 forwardReference
Dimensions
Weight11702 kgReference
Rear tire72x24Reference
Ag rear72x24 (steel)Reference
Length566 cmReference
Width266 cmReference
Height320 cmReference
Rear axle123 mmReference
Capacities
Diameter81 cmReference
Width31 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
