Tractor · 1956Unverified
J.I. Case 302
J.I. Case 302 — 300 Series · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
1859 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
High-Clearance tractorReference
Built in Rock Island, Illinois, USAReference
Total built7Reference
Original price$3,600 (1958)Reference
Two-wheel driveReference
SteeringmanualReference
6-inch disc brakesReference
Open operator station.Reference
Variants
300diesel utilityReference
301diesel row-cropReference
302diesel high-cropReference
310gasoline utilityReference
311gasoline row-cropReference
312gasoline high-cropReference
320industrialReference
Engine
Continental 2.6L 4-cyl dieselReference
Drawbar (claimed)16.4 kWReference
Belt (claimed)20.1 kWReference
Plows3Reference
Continental GD157Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.6 LReference
Bore/Stroke86 x 111 mmReference
Air cleaneroil bathReference
Pre-heatingetherReference
Compression15.5:1Reference
Rated RPM1750Reference
Starter volts12Reference
Coolant capacity11.4 LReference
Transmission
4-speed sliding gearReference
12-speedReference
Typesliding gearReference
Gears4 forward and 1 reverseReference
Clutch234.9mm dry discReference
TransmissionTripl-RangeReference
Gears12 forward and 3 reverseReference
Clutch234.9mm dry disc (master foot clutch)Reference
Clutchwet discs (traction hand clutch)Reference
Four gears (1-4) plus reverse (R) in three ranges (low, direct, high).Reference
Dimensions
Weight1859 kgReference
302 Serial Numbers
Location:Instrument panelReference
19566050301Reference
19576075001Reference
19586095001Reference
FAQ: How to read a serial number table.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
